Why Standard Schedules Fail Intricate Murrine
Standard fusing schedules often prioritize speed and achieving a homogenous melt. While effective for fusing large, simple pieces or slumping blanks, this approach can wreak havoc on delicate murrine patterns:- Pattern Distortion: Rapid heating causes the outer edges of the murrine assembly to soften and flow before the interior reaches the same viscosity. This differential movement can stretch, compress, or completely obliterate the carefully constructed pattern.
- Loss of Detail: Holding the glass at peak fusing temperatures for extended periods, typical in full fuse schedules, encourages glass flow. While this creates a smooth surface, it also allows fine lines and small elements within the murrine to blur or disappear entirely.
- Color Bleeding: Excessive heat or prolonged soaks at high temperatures can cause adjacent colors within the murrine cane, and between slices, to bleed into one another, muddying the design.
- Trapped Air Bubbles: When murrine slices are packed tightly, tiny air pockets inevitably get trapped between them. Standard fast ramps quickly seal the surface layer of glass before this trapped air has a chance to escape, resulting in unsightly bubbles, often obscuring the pattern.
Core Elements of Advanced Murrine Fusing Schedules
Advanced schedules leverage specific techniques during the heating and cooling phases to maintain pattern integrity and minimize flaws. The key is understanding the purpose behind each segment of the schedule.Slower Ramps are Your Friend
Heating the glass slowly, especially through certain temperature ranges, is fundamental. Why?- Even Heating: Slower ramps allow heat to penetrate the glass assembly more evenly, reducing the temperature differential between the core and the exterior. This minimizes internal stresses and reduces the tendency for outer elements to melt and distort prematurely. Recommended ramp rates might be as low as 200-300°F (111-167°C) per hour in critical zones, compared to standard ramps of 500°F (278°C) per hour or more.
- Controlled Softening: Glass doesn’t melt instantly; it goes through a gradual softening process (viscosity change). Slow ramps allow you to approach target temperatures gently, giving you more control over *when* significant movement begins.
Strategic Temperature Holds (Soaks)
Holds at specific temperatures are arguably the most critical part of an advanced murrine schedule. They allow time for specific physical processes to occur without rushing to the next stage. Lower Temperature Holds (Bubble Squeeze): Typically implemented between 1000°F and 1250°F (538°C – 677°C), these holds are crucial for dealing with trapped air. At these temperatures, the glass begins to soften slightly, but isn’t yet fluid enough to seal completely shut. A hold of 30 to 90 minutes allows the heating glass to ‘squeeze’ trapped air out through tiny channels that still exist between the murrine components. Skipping or shortening this hold is a primary cause of bubbles in tightly packed murrine work. Mid-Range Holds (Consolidation & Initial Fuse): Soaking the glass somewhere between 1250°F and 1400°F (677°C – 760°C), depending on the glass COE and desired effect, allows the murrine elements to begin sticking together (sintering) and consolidating *before* reaching temperatures that cause significant flow. This helps ‘lock in’ the pattern. The exact temperature and duration depend heavily on the glass being used and how much fusing is desired at this stage. For maintaining maximum detail, you might aim for a tack fuse or slightly beyond, rather than a full fuse. Top Temperature Holds (Achieving the Final Fuse): This is where the magic happens, but also where patterns are most vulnerable. For intricate murrine, the goal is often *not* a traditional, flat full fuse, which would likely erase detail. Instead, the top temperature might be slightly lower than a typical full fuse, and the hold time significantly shorter – perhaps only 5 to 15 minutes. The aim is to fuse the elements sufficiently for structural integrity while minimizing glass movement and distortion.Important: These temperature ranges are illustrative. Specific values depend heavily on the Coefficient of Expansion (COE) of your glass (e.g., COE 90, COE 96), the brand of glass, the size and thickness of your project, and your specific kiln’s performance. Always conduct tests with your specific materials and equipment.
Controlled Cooling and Annealing
Just as heating requires care, so does cooling. Crashing the temperature too quickly after the top soak can introduce thermal shock, especially in complex pieces with many internal interfaces. Cooling to Annealing Range: While some schedules advocate rapid cooling from the peak temperature down to the annealing range to ‘freeze’ the design, this must be balanced against thermal shock risk. A controlled, but not necessarily slow, ramp down might be appropriate. Annealing Soak: This is non-negotiable. Murrine assemblies, with their multiple components and potential for internal stress, require thorough annealing. The annealing temperature depends on the glass COE (e.g., around 900-960°F / 482-516°C for COE 96, or 950-1000°F / 510-538°C for COE 90). The hold time should be generous, often longer than for a simple sheet of glass, especially for thicker pieces. An hour or more is common. Slow Cooling to Room Temperature: After the annealing soak, cooling must proceed slowly through the strain point and down to room temperature. Rushing this phase is a primary cause of delayed cracking. Rates of 100-150°F (56-83°C) per hour down to below 700°F (371°C) are often recommended, sometimes even slower for very thick or complex pieces.Developing and Refining Your Schedules
There’s no single “magic” schedule for all intricate murrine. Success comes from understanding the principles and applying them through careful testing and observation.Start with Baselines, Then Adapt
Use manufacturer-recommended schedules for your specific glass COE as a starting point. However, recognize these are often designed for simpler fusing. Begin by incorporating slower ramps and adding a bubble squeeze hold based on the principles above.The Power of Testing
Test relentlessly. Before committing a large, complex murrine assembly, fire small test pieces or individual slices using your proposed schedule.- Use the exact same glass types and COE.
- Mimic the thickness and density of your final piece as closely as possible.
- Keep meticulous notes: schedule used, glass details, kiln used, visual results (bubbles, distortion, fuse level, clarity). Photos are invaluable.
- Change only one variable at a time between tests (e.g., change only the bubble squeeze duration, or only the top temperature).
Factor in Variables
Glass Properties: Opalescent glasses often slump less readily than transparents. Reactive glasses might need specific temperature controls to achieve desired effects. Dark colours absorb radiant heat faster than light colours, potentially leading to uneven heating in mixed assemblies. Kiln Quirks: Every kiln fires slightly differently. Know your kiln’s hot and cold spots. A schedule that works perfectly in one kiln might need adjustment in another. Consider using witness cones initially to verify your controller’s accuracy. Project Size & Thickness: Larger and thicker assemblies require significantly slower ramps and longer annealing holds to ensure even heating/cooling and proper stress relief.Verified Tip: Documenting your tests is crucial for reproducibility. Create a logbook detailing the date, project description, glass used (COE, colours, manufacturer), full firing schedule programmed, placement in the kiln, and observed results including photos. This systematic approach accelerates learning and troubleshooting.
Troubleshooting Common Murrine Fusing Problems
Even with careful planning, issues can arise. Understanding the likely causes helps in refining your schedules:- Pattern looks ‘squashed’ or distorted: Likely culprits include heating too quickly (especially the ramp to top temperature), holding the peak temperature too long, or the peak temperature being simply too high for the desired level of detail preservation. Try reducing ramp speeds, shortening the top hold, or lowering the top temperature slightly.
- Persistent bubbles within the pattern: Usually indicates an insufficient bubble squeeze. Try lengthening the hold time at the bubble squeeze temperature (e.g., 1150°F/620°C) or slowing the ramp leading up to it. Ensure murrine slices are clean before assembly.
- Milky or hazy surface (Devitrification): Can be caused by holding the glass for too long in the devitrification temperature range (often around 1300-1550°F / 700-840°C, but varies by glass type), contaminants on the glass, or incompatible glasses. Ensure glass is clean and review hold times in the critical range. Sometimes specific overglazes or firing sprays can help prevent devit.
- Cracking (immediately or days later): Almost always an annealing issue. The annealing hold might be too short, the temperature incorrect for the glass type, or the cooling rate after the annealing hold is too fast. Review your entire cooling segment, especially the rate below 1000°F (538°C).
